  • * Describing a track corner as a clock face entering the corner at 3:00 and exiting at 9:00

    + Increasing LR Trailing Arm angle increases drive which tightens the chassis but also adds dynamic LR lead which will have counter effects. Balance with overall Lead/Trail adjustments when changed significantly.

    PDF VERSION OF GUIDE

Sponsoring Dirt Race Life

Dirt Race Life is how I share working hard to become a better driver and a better builder all while growing the knowledge needed to be a setup guy who can explain it in videos in a better way that helps other racers like me. I love this sport and sharing it with others and I hope you do too.

Do you enjoy the channel? Are these the kind of videos that you want to see? Well I could sure use the help to be able to do this. Below are links to make a one time donation to Dirt Race Life. Your Sponsorship buys the parts we need for the cars as well as helps me be able to make Dirt Race Life videos.

1 4

Metric Street Stock Setup (6th Run @ Clayhill,Atwood, TN July, 20th, 2024)

  • Springs, Shocks, and Ride Heights

    • LF- 1050lb 9.5" Spring, 300R/130C Shock
    • LF Height @ Bolt: 7 3/8"
    • RF- 950lb 9.5" Spring With 2.5" Drop & Bearing, 500R/130C Shock W/BV
    • RF Height @ Bolt: 7 1/4"
    • LR- 125lb 16" Spring, 75/550 Shock W/SRT&BV
    • LR Height @ Bolt: 10 1/2" (10 degrees)
    • RR- 230/250lb 13" with 2.5" Drop Cup, 40R/110C W/STR&BV
    • RR Height @ Bolt: 10 1/4" (2 degrees)

  • Scales and Details

    • Left Side= 52.7%
    • Rear= 54.0%
    • Cross= 51.8%
    • LR Bite= 25lbs
    • Total Weight= 3090lb
    • Camber: LF +4.0, RF -6.5
    • Caster: LF +3.5, RF +5.5
    • Anti/Pro Dive: LF@3 Pro, RF@0
    • LF Droop: 1.25", LR Droop: 4.5"
    • LR Preload: 250lbs
    • LR Lead @ Ride height is 3/4"
    • 3" Wheel Offset: LF, RF, & LR
    • 4" Wheel Offset: RR

Product Links from Episodes

Tools and Setup Equipment


  Geometry Compass Power Shears

Motorized Tire Stand Build List

  SOUTHWEST WHEEL R30484X 84 Spindle & 5-5" Bolt Circle Trailer Hub

Brake Components



Suspension Components


Engine Assembly and Maintenance Items

 Thread Sealant for Head Bolts Best Silicone for Exhaust Headers Inexpensive SBC Head Bolts SBC Cylinder Head Dowel Pins

FUEL SYSTEM COMPONENTS



Wiring & Electronics

Latest Episodes (By Playlist)

Metric Frame Street Stock Build

73-77 Chassis Street Stock Build

Chassis Set-up, Adjustment, and Race Prep

Engine Building, Maintenance, & Tuning

Track Side Action

YouTube Live DRL

Product Review Episodes

Blueprint and Drawing Library

Blueprint and Drawing Library

CENTER LINK DIMENSIONS, WHICH ONE DO YOU NEED?

Every build is different and there is no guarantee that what works on one car will be right for another. Its important to set your steering sector arm and idle arm exactly parallel with a center link that matches that requirement.

BLUE PRINT, CHEVELLE, 1970

BLUE PRINT, LARGE METRIC, 1981

BLUE PRINT, SMALL METRIC, 1980

BLUE PRINT, SAGINAW 3 SPEED

SPARK PLUG HEAT RANGING

I have had good success with the NGK spark plugs running my builds that use vortec heads. Here's what I have learned about finding the ideal heat range. The crate 602 likes the #8 due to it's limited compression. In a 10 to1 compression build the #9 was perfect and when I have run more than 11 to 1 compression, the #10 plug worked well. Remember, for NGK plugs ranging is higher number = cooler plug!

REAR ROLL CENTER, 4 LINK W SUSPENSION
